Introduction

This article delves into a specific bug encountered when using the facet-kdl crate in Rust, particularly when dealing with structs that have multiple Vec<T> fields annotated with the #[facet(kdl::children)] attribute. This bug leads to parsing failures, and this article aims to explain the cause, reproduction steps, expected vs. actual behavior, and a potential design solution.

Bug Description: The Core Issue

The problem arises when a struct contains several Vec<T> fields, each marked with the #[facet(kdl::children)] attribute. In such cases, facet-kdl incorrectly attempts to parse all child nodes as if they were of the same type as the first field encountered with that attribute. This misinterpretation results in parsing failures, especially when the child nodes are intended to map to different fields based on their unique node names. Basically, facet-kdl gets confused when it sees multiple potential targets for child nodes and defaults to the first one it finds, regardless of whether that's the correct match for a particular node.

Reproduction: How to Trigger the Bug

To illustrate this bug, consider the following Rust code snippet:

use facet::Facet;

#[derive(Debug, Clone, Facet)]
struct Config {
 #[facet(kdl::children, default)]
 pub dependencies: Vec<Dependency>,

 #[facet(kdl::children, default)]
 pub samples: Vec<Sample>,
}

#[derive(Debug, Clone, Facet)]
struct Dependency {
 #[facet(kdl::argument)]
 pub npm_name: String,

 #[facet(kdl::property)]
 pub crate_name: String,
}

#[derive(Debug, Clone, Facet)]
struct Sample {
 #[facet(kdl::child)]
 pub path: String,

 #[facet(kdl::child, default)]
 pub description: Option<String>,
}

fn main() {
 let kdl_content = r#"
sample {
 path "test.txt"
 description "A test file"
 }
"#;

 let config: Config = facet_kdl::from_str(kdl_content).unwrap();
 // Expected: Config with empty dependencies and one sample
 // Actual: Fails with "Value 'Dependency' was not initialized"
}

In this example, we define a Config struct with two fields: dependencies (a Vec<Dependency>) and samples (a Vec<Sample>), both marked with #[facet(kdl::children)]. The KDL content defines a sample node. The intention is for facet-kdl to parse this KDL content and populate the samples field with a Sample instance. However, when running this code, it results in a parsing error.

Expected Behavior: What Should Happen

Ideally, the KDL should be parsed successfully, resulting in a Config struct with the following state:

  • dependencies: An empty Vec<Dependency> (because there are no dependency nodes in the KDL content).
  • samples: A Vec<Sample> containing one element, representing the sample node defined in the KDL.

The node name (sample vs. dependency) should be the key factor in determining which field the node maps to. facet-kdl should intelligently route the sample node to the samples field and correctly parse it as a Sample instance.

Actual Behavior: The Error Unveiled

Instead of the expected behavior, the parsing process fails with the following error message:

Error kind: Reflect(ReflectError(Value 'Dependency' was not initialized))

This error reveals that facet-kdl is attempting to parse the sample node as a Dependency instance. This fails because the sample node lacks the required npm_name argument and crate_name property that are mandatory for the Dependency struct. This confirms that facet-kdl is incorrectly associating the sample node with the dependencies field.

Additional Observations: Further Insights

Further investigation reveals some interesting insights:

  • Single samples field: If the Config struct only contains the samples field (and not the dependencies field), parsing the sample node still fails, but with a different error: NoMatchingArgument. This suggests that even in the absence of the dependencies field, facet-kdl is not correctly identifying the structure of the sample node and mapping it to the Sample struct's fields.
  • Single dependencies field: Conversely, if the Config struct only contains the dependencies field, parsing dependency nodes works correctly. This indicates that the #[facet(kdl::children)] attribute functions as expected when there's only one such field in the struct. The issue only arises when there are multiple fields with this attribute.

These observations strongly suggest that #[facet(kdl::children)] expects all child nodes to conform to a single type, ignoring the node name. This is a significant limitation that prevents the parsing of KDL structures with diverse child node types.

Expected Design: A Possible Solution

To address this bug, the #[facet(kdl::children)] attribute should be enhanced to intelligently match child nodes based on one of the following criteria:

  1. Node name matching the field name: The node name (in singular form) should match the field name. For example, a sample node should map to the samples field.
  2. Node name matching the type name: The node name should match the type name of the field's element type. For example, a dependency node should map to a Vec<Dependency> field.
  3. Explicit node_name attribute: Introduce an explicit attribute like #[facet(kdl::children, node_name = "sample")] to explicitly specify which node name should be mapped to the field. This would provide the most control and flexibility.

By implementing one or more of these matching strategies, facet-kdl can correctly parse KDL structures with multiple #[facet(kdl::children)] fields, enabling more complex and realistic configuration scenarios. This would allow developers to define structs that can represent KDL documents with a variety of different child node types, greatly increasing the utility of the facet-kdl crate.

Environment: Details of the Setup

The bug was observed in the following environment:

  • facet version: 0.31.8
  • facet-kdl version: latest from git

Conclusion

The presence of multiple #[facet(kdl::children)] fields leads to parsing failures due to the library attempting to parse all child nodes as the same type, regardless of the node name. The library needs to improve how it associates KDL nodes with the fields in a struct with multiple #[facet(kdl::children)] attributes. A possible solution involves using the node name (singular or type name) or adding an explicit attribute to specify the node name. This fix would greatly enhance the library's ability to parse complex KDL structures. For more information on KDL and its specifications, please visit the KDL official website.
