Fixing Smooth Shading Issues In Mineways OBJ Imports

Hey everyone! Have you ever imported a 3D model created with Mineways and noticed some weird shading issues? You're not alone! It's a common problem where smooth shading causes rendering artifacts. I'll explain what's happening and how to fix it, so you can get those Minecraft creations looking their best. Let's dive into why these issues pop up and what you can do about it.

Understanding the Problem: Smooth Shading Artifacts

When you import a 3D model (like an OBJ file) into a 3D software or game engine, it needs to know how to render the surfaces. Smooth shading is one way of doing this. It tries to create a smooth transition of colors across the surface of the model. This is usually great for round objects, but it can cause problems with blocky Minecraft models. In Minecraft, everything is made of cubes, so it looks best when each face is clearly defined. When smooth shading is applied, the edges of the blocks can look rounded or have strange lighting effects, creating rendering artifacts.

The images provided in the original question perfectly illustrate this problem. You can see how the smooth shading is creating unwanted gradients and making the blocky structure of the model appear distorted. These artifacts can really detract from the overall look of your model, making it look blurry or unnatural. The issue isn't with the model itself, but rather with how the software is interpreting the shading data within the OBJ file.

In contrast, exports from tools like jmc2OBJ usually don't have this problem. This suggests that the way Mineways handles vertex normals (which are the data used for smooth shading) might be the key. Vertex normals define the direction a surface is facing at each vertex (corner) of a polygon. Mineways might be setting these normals in a way that is causing the smooth shading to misinterpret the blocky nature of the Minecraft models.

Recent changes in either Mineways or the importing software might have introduced or exacerbated this issue. It's also important to note that the problem may not always appear, but when it does, it's quite noticeable and can ruin the visual appeal of your imported model.

Why Does This Happen with Mineways?

It's not entirely clear why Mineways specifically is causing this issue, but we can make some educated guesses. Mineways, as a tool, is designed to extract and convert Minecraft worlds into various 3D formats. The problem likely stems from how Mineways handles the vertex normals in the exported OBJ files. Vertex normals are crucial for smooth shading, as they dictate how light interacts with the surface of the model.

• Vertex Normal Calculation: Mineways might be calculating vertex normals in a way that's not ideal for the blocky nature of Minecraft. When a model has sharp corners (like Minecraft blocks), each face should ideally have a distinct normal. If Mineways is smoothing these normals across multiple faces, it creates the illusion of rounded edges and causes shading artifacts. Tools like jmc2OBJ may handle normal calculations differently, resulting in a cleaner look.
• OBJ File Format Specifics: The OBJ file format itself is quite flexible, and the way the data is structured can influence how it's interpreted by different software. Minor variations in how Mineways exports the data could be a contributing factor. The importing software might interpret these variations differently, leading to inconsistent results.
• Software Compatibility: The software you're importing the OBJ files into (Blender, Unity, etc.) also plays a role. Different software packages have different default settings for importing OBJ files, which could affect how smooth shading is applied. If the software's default setting is to use smooth shading, it will automatically try to smooth the surfaces, leading to the problems you're seeing.
• Recent Updates: As mentioned, the issue might be recent. Updates to Mineways or the importing software could have changed how vertex normals are handled. This can sometimes introduce or worsen compatibility issues.

The Simple Solution: Shade Flat

The good news is that there's a simple fix! The best solution is to use "Shade Flat" in your 3D software. This setting tells the software to treat each face of the model as a separate, flat surface. This eliminates the smooth shading and makes the model look like the original Minecraft blocks. The artifacts disappear, and you get the sharp, clean look you're after.

• How to Apply Shade Flat:
  • In Blender: Select your imported OBJ model. Go to the Object menu in the viewport, then select
